Citizen CL-S621 User Manual

2
Printer Operation
44
Manually Selecting the Printer Emulation
To manually choose between Datamax
®
and Zebra
®
emulations, you can use
the VuePrint menu system. The Emulation Select option in the System Setup
menu allows you to do this.
Alternatively, you can use the “Quick Switch” option as follows:
1. Turn on the printer holding down PAUSE and FEED keys together.
The printer will beep three times and the CONDITION LED will
flash.
2. Press FEED key once for Datamax
®
emulation.
3. Press FEED key two times for Zebra
®
emulation.
The printer beeps each time the feed key is pressed.
4. To save the new selection, press MODE/REPEAT key. The printer
will beep three times and then restarts.
Menu Setting Table
(p.37, p.40)

Citizen CL-S621 Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 DPI
RS-232 ports	1
RS-232 interface	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Ethernet, Parallel, Wireless LAN
Connectivity technology	Wired
Flash memory	4 MB
Internal memory	16 MB
Compatible operating systems	Windows, XP, 2003, 2008, Vista, Windows 7
Media thickness	0.0635 - 0.254 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Product color	Gray

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	270 mm
Weight	4500 g
