Citizen CL-S621 - Part Names and Functions (Inside the printer)

1
Setup
12
2
1
4
3
Part Names and Functions
1 Ribbon drive unit
2 Head close knob
Push the head close knob to lock the mechanism closed. If you push on
another part of the mechanism, the printer may not lock closed correctly.
3 Ribbon holder
It is used to attach the ribbon and paper core.
4 Front cover
It is removed to install optional units such as the peeler or cutter.
Inside the printer
