Chapter 1 Setup
Part Names and Functions
Inside the printer
2
1
4
3
1
Ribbon drive unit
2
Head close knob
Push the head close knob to lock the mechanism closed. If you push
on another part of the mechanism, the printer may not lock closed
correctly.
3
Ribbon holder
It is used to attach the ribbon and paper core.
4
Front cover
It is removed to install optional units such as the peeler or cutter.
