Citizen CL-S6621 - Page 41

41
Chapter 2 Printer Operation

Zebra® Emulation
Top Menu Sub Menu Default Menu Remarks
Global
conguration
– Cong Set 1 Cong Set 1
Cong Set 2
Cong Set 3
Sets the Cong Set.
Page Setup Print Speed 6 IPS 2 to 6 IPS Printing speed setting.
Print Darkness 10 00 to 30 Print darkness setting
(printhead temperature)
Darkness Adjust 0 -10 to 10 Darkness command adjustment
Print Method Thermal transfer Thermal transfer
Direct thermal
Selecting thermal transfer (ribbon)/direct
thermal media
Ribbon Winding Outside Outside
Inside
Selecting the ribbon winding direction.
Continuous Media
Length
4.00 inch
101.6 mm
0.25 to 99.99 inch
6.40 to 2539.7 mm
Setting default length of continuous media,
if selected. ; the lower line is in metric mode.
Vertical Position 0.00 inch
0.0 mm
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Print start position adjustment
Horizontal Shift 0.00 inch
0.0 mm
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Horizontal printing location adjustment
Vertical Image Shift 000 dots -120 to 120 dots Adjust the o set value in vertical when
mapping data on a RAM.
Auto Side Shift 00 dots 00 to 15 dots Allows horizontal shifting of printing
position by specied number of dots per
page. Eective when load is applied to a
specic head area, like vertical lines.
Media Sensor See Through See Through
Reect
None
Label sensor selection
Small Media
Adjustment
O On
O
Setting for small labels
Small Media Length 1.00 inch
25.4 mm
0.25 to 1.00 inch
6.40 to 25.4 mm
Setting length of small label media
System Setup
Sensor Level 1.7 V 0.0 V to 3.3 V Setting the threshold of the sensor
Paper End Level 2.80 V 0.01 to 3.00 V Sets the paper end level.
Error Reporting On Printing
On Printing
Immediate
Setting for error report.
Buzzer Select On On
O
Setting buzzer sounding conditions
Metric/Inch Inch Inch
mm
Setting the units used
Max Media Length 10.00 inch
254.0 mm
1.00 to 99.99 inch
25. 4 to 2539.7 mm
Setting the maximum label length
Settings Lock O On
O
When on, prevents software commands
from changing the values set by the VuePrint
menu
Keyboard Lock O On
O
Prevents the control panel from aecting
the printer’s conguration. (User “lock-out”)
Mode Settings
[Zebra® Emulation]
