Citizen CLP-521 User Manual

29
Printer Operation
Mode Settings
SAVE
SAVE
SAVE
SAVE
SAVE
SAVE
YES / Select / SAVE NO / Next Item / Change Value
Next Digit
Exit to previous menu
EXIT
YES
YES
Change
Value
Change
Value
Change
Value
YES
YES
• Continuous Media Length
• Vertical Position
• Horizontal Shift
• Media Sensor
• Small Media Adjustment
• Sensor Level
• Buzzer Select
• Metric/Inch
• Max Media Length
• Settings Lock
• Keyboard Lock
• Control Code (DMX Mode Only)
• Emulation Select
• Function Select
• Cutter Action
• Paper Position
• Mode/Repeat Key
• RS-232C Baud
• RS-232C Parity
• RS-232C Length
• RS-232C Stop bit
• RS-232C X-ON
• IEEE1284
EXIT
EXIT
EXIT
EXIT
EXIT
Changing the
parameter
Print Speed
Print Darkness
Small Media Length
Operation Panel
Changing the
parameter
Changing the
parameter

Citizen CLP-521 Specifications

General

Print technology	Direct thermal
USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000/XP
Flash memory	2 MB
Certification	UL, C-UL, FCC: class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Core diameter	25.4 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	104 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	186 mm
