14
CT-S300 Service Manual
Ref.
No.
Parts No. Description
RPU
Remarks
31 200041-00 PE PCB Assy SEC-3784 (1) (1) (1)
32 500322-00 PE PCB Holder 1 1 1
33 90-0197 PNE PCB Assy SEC-2856 (1) (1) (1) 1 PNE sensor
200055-00 2 PNE sensors
(25-0379) (PNE Cable Assy) SEC-2854 1 1 1
34 600374-00 PNE Lever 1 1 1 1 PNE sensor
600408-00 2 PNE sensors
35 600375-00 PNE Cap 1 1 1 1 PNE sensor
600409-00 2 PNE sensors
36 200036-00 Switch Assy (1) (1) (1)
(Leaf Switch MLS-29Au) 1 1 1
(200035-00) (SW Cable Assy) SEC- 1 1 1
(200040-00) (BM PCB Assy) (1) (1) (1) Black mark option
(200039-00) (BM Cable Assy) 1 1 1 Black mark option
37 32AD AC Adapter 32AD 1 1 1
38 25-0370 AC Cord 100V SEC-2706 1 1 1
39 Plug converter MPR-25B (Black) 1 1 1
38 25-0102 AC Cord 120V SEC-1003
38 25-0103 AC Cord 230V SEC-1004
50 F13630-06 Screw, PHT (ST), M3 × 6 with washer 1 1 1
51 F10230-06 Screw, PHT (ST), M3 × 6101010
52 F11130-08 Screw, PHT (BT), M3 × 8333
53 F11230-10 Screw, PHT (BT), M3 × 10 2 2 2
54 F13417-06 Screw, No0PHT (BT#1), M1.7 × 7111
55 F10430-08 Screw, PHT (ST), M3 × 8222
56 600380-00 Partition 1 1 1 Standard accessory
60-1 950031-00 Control PCB Assy JPN (1) (1) (1) For 100V model
1 PNE sensor
950031-10 2 PNE sensors
60-1 950032-00 Control PCB Assy USA/EUR (1) (1) (1) For 120/230V model
1 PNE sensor
950032-10 2 PNE sensors
61-1 950033-00 IF PCB Assy (Serial) mm (1) Metric screw
61-2 950034-00 IF PCB Assy (Serial) inch (1) Inch screw
61-3 950035-00 IF PCB Assy (Parallel) (1)
61-4 950036-00 IF PCB Assy (USB) (1)
Q’ty
