52
——
3.12 Loading Paper
1. Turn on the power.
2. Press the cover release buttons on both the right and left sides to open the top cover.
3. Load the roll paper with the printable side of the paper facing outward as shown by
arrow A and with no slack.
4. Pull a few centimeters of paper straight out in the direction of arrow B.

Citizen CT-S4500 Specifications

General

Cutter	Yes
Certification	CE, UL, C-UL, FCC, VCCI
Internal memory	0.384 MB
Built-in barcodes	CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, PDF417, QR Code, UPC-A, UPC-E
Page description languages	ESC/POS
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Serial interface	No
Optional connectivity	Bluetooth, Ethernet, Serial (RS-232), USB 2.0, Wireless LAN
Connectivity technology	Wired
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum roll diameter	102 mm
Supported paper width	58 - 112 mm
Maximum printing width	104 mm
Printing media thickness	65 - 150 µm
Product color	Black
Character sets	852, 857, 863, 864, 866, Katakana, Thai code 18, WPC1252
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1

Weight and Dimensions

Depth	216 mm
Width	170 mm
Height	151 mm
