CZ Series Precision Balances service manual
- 10 -
9.4 PARTS LIST
No
Parts name qty material Spec
1
Wind shielding top cover 1
AL
2
toughened glass 1 2
glass 152.5x80x3t
3
pole for glass 4
AL
4
toughened glass 2 2
glass 138.5x80x3t
5
SST pan 1
SUS304 80/120
6
"+" screw 1
S18C M4x10, 6.8
7
plastic pan 1
ABS 80/120
8
SST cover 1
SUS304 0.5t
9
top cover 1
ABS
10
internal hexagon screw 4
M3x12,8.8
11
load cell shim 2
SUS304 16x13x1t
12
load cell upper bracket 1
ABS
13
battery 1
lead acid 6v/1.2Ah
14
self thread screw 10
S18C 3x8, 6.8
15
interface PCBA 1
RS232/USB
16
"+" screw 4
S18C M4x12, 6.8
17
load cell lower bracket 1
AL
18
bottom cover 1
ABS
19
Level bubble 1
14.7mm
20
key panel 1
PC
21
dislay PCBA 1
22
insulative washer 10
EDPM 8x3.1x1.5t
23
"+" screw 10
S18C M3x12,8.8
24
below weighing sheet 1
25
load cell 1
AL SPL
26
"+" screw 1
S18C M3x10, 6.8
27
"+" screw (big head) 1
SUS304 M3x12
28
Main PCBA 1
29
below weighing screw 1
30
"+" screw 4
S18C M4x12, 8.8
31
foot 1 2
ABS
32
foot 2 2
ABS
