CZ Series Precision Balances service manual
- 10 -
SECTION 7 PARAMETERS
NOTE: If the user wants to enter into the technical parameter, the jumper K1 on the
main board must be short firstly.
The scale has 8 parameters that can be set by the user plus a method of entering the
calibration section.
To set parameters press the MODE key during self checking
The display will show the first function, "F1 UNT".
Pressing the MODE key will cycle through the other functions.
Pressing ZERO key will allow you to set the function. Use the PRINT/ESC key to
leave a parameter unchanged.
Attached: When display shows “TECH”, press ZERO key to enter, display shows
“PIN”, press S, PRINT, TARE key, and press ZERO key to enter technical parameters
setting mode.
Parameters table.
FUNCTION
DESCRIPTION
F1 UNT Sets the which units want to use: g
/
ct / lb / oz / dr / ozt / dwt, use
MODE to switch (ON/OFF), use ZERO key to sure.
F2 Bl Set the backlight to be on, automatic or off,
EL on: EL backlight always on
EL Au: EL backlight automatically turn on
EL off: El backlight always off
Use MODE key to switch, use ZERO key to sure
F3 cal
Normal calibrate
After enter cal mode, the display will show "unLoAd". Remove all
weight from the pan and wait for stable
After stable, balance will show load c, put put calibrate weight on
the pan, here is the useable weight list
Balance capacity 500g: calibration weight 500g
Balance capacity 600g: calibration weight 500g
Balance capacity 1200g: calibration weight 1000g
Balance capacity 5000g: calibration weight 5000g
Balance capacity 6000g: calibration weight 5000g
after stable, display will show pass, calibrate complete.
No need press any key during calibrate.
TECH Pin Enter the programming and calibration menus by entering the
correct password (S, Print, TARE) and press ZERO key to enter.
