- 10 -
SECTION 8 APPENDIX
9.1 ERROR CODES
During the initial power-on testing or during operation it is possible the scale may
show an error message. The meaning of the error messages is described below.
If an error message is shown repeat the procedure that caused the message, turning
the balance on, calibration or other functions. If the error message still is shown
then contact your dealer for further support.
ERROR CODE DESCRIPTION POSSIBLE CAUSES
Err 3
Calibrate weight error Use incorrect calibrate weight
Err 4
Initial Zero is greater than
allowed (4% of maximum
capacity) when power is
turned on or when the
ZERO/ENTER key is
pressed,
Weight on the pan when turning the
scale on.
Excessive weight on the pan when
zeroing the scale.
Improper calibration of the scale.
Damaged load cell.
Damaged Electronics.
Err 5
Keyboard Error. Improper operation of the scale.
Err 6
A/D count is not correct
when turning the scale on.
Platform not installed.
Load cell damaged.
Electronics damaged.
Err 17
Unstable Mode Tare or Zero Key Press Without
Stability [ Wait For Stability Sign]
9.2 WEIGHING UNIT LISTING
No Unit mark Unit name
Conversion（g）
1
G
Gram
2
Ct
net carat =0.2g
3
Lb
Lb =453.59237g
4
Oz
Ounce =28.349523125g
5
Dr
Dram =1.7718451g
6
Ozt
troy ounce =31.1034768g
7
Dwt
penny weight =1.55517384g

Citizen CZ series Specifications

General

Model	CZ series
Display	LCD
Overload Indicator	Yes
Low Battery Indicator	Yes
Pan Size	Varies by model
Weighing Units	g, oz, ct, dwt, ozt
Calibration	External Calibration
Auto Power Off	Yes
Material	Stainless steel
Power	AC Adapter (included) or 4 x AA batteries (not included)
