Citrix ADC MPX
Citrix ADC appliances do not support transceivers from vendors other than Citrix Systems. At-
tempting to install third-party transceivers on your Citrix ADC appliance voids the warranty.
Do not install the transceivers with the cables attached. Doing so can damage the cable, the
connector, or the optical interface of the transceiver.
Frequent installation and removal of transceivers shortens their life span. Follow the removal
procedure carefully to avoid damaging the transceiver or the appliance.
Install a transceiver
1. Remove the transceiver carefully from its box.
Danger: Do not look directly into fiber optic transceivers or cables. They emit laser beams that
can damage your eyes.
2. Align the transceiver to the front of the appropriate transceiver port on the front panel of the
appliance.
Note: The illustration in the following figures might not represent your actual appliance.
Figure 6. Install a transceiver
3. Hold the transceiver between your thumb and index finger and insert it into the transceiver port.
Press it in until you hear the transceiver snap into place.
4. Lock the transceiver.
© 1999‒2022 Citrix Systems, Inc. All rights reserved. 141
