Citrix ADC MPX 25100T
September 19, 2022
The Citrix ADC MPX 25100T and 25160T are 2U appliances. Each model has two 10-core processors and
128 GB of memory. The MPX 25100T/25160T appliances are available in the thirty-two 10G SFP+ ports
(32x10G SFP+) configuration.
Note: The MPX 25000T appliances are not RAID (redundant array of independent disks) devices.
The following figure shows the front panel of the MPX 25100T/25160T (32x10G SFP+) appliance.
Figure 1. Citrix ADC MPX 25100T/25160T (32x10G SFP+), front panel
Depending on the model, the appliance has the following ports:
• RS232 serial Console Port.
• 10/100Base-T copper Ethernet Port (RJ45), also called the LOM port. You can use this port to
remotely monitor and manage the appliance independently of the Citrix ADC soware.
• Two 10/100/1000Base-T copper Ethernet Management Ports (RJ45), numbered 0/1 and 0/2 from
le to right. These ports are used to connect directly to the appliance for system administration
functions.
• Network Ports, thirty-two 10G SFP+ ports (32x10G SFP+).
Note: The 10G SFP+ ports on these appliances support copper 1G SFP transceivers.
The following figure shows the back panel of the MPX 25100T/25160T appliance.
Figure 2. Citrix ADC MPX 25100T/25160T, back panel
