Citrix ADC MPX
Health Attribute Recommended Range
CPU 0 core (Volts) 0.85–0.91
CPU 1 core Volt 0.85–0.93
Main 3.3 V Supply (Volts) 3.31–3.36
Standby 3.3 V Supply (Volts) 3.26–3.31
+5.0 V Supply (Volts) 4.99–5.06
+12.0 V Supply (Volts) 11.98–12.08
Battery Voltage 3.02–3.12
Internal CPU Vtt Power 0.99–1.01
CPU Fan 0 Speed (RPM) 1875–4350
CPU Fan 1 Speed (RPM) 1875–4200
System Fan Speed (RPM) 1875–4350
System Fan 1 Speed (RPM) 1875–4275
System Fan 2 Speed (RPM) 1875–4200
CPU 0 Temperature (Celsius) 33–43
CPU 1 Temperature (Celsius) 35–45
Internal Temperature (Celsius) 28–38
Power Supply 1 Status NORMAL
Power Supply 2 Status NORMAL
Health attributes for the MPX 22040 platform
The following table lists the health attributes for the MPX 22040 platform.
Health
attribute Unit
Lower
Non-
Recoverable
Lower
Critical
Lower
Non-
Critical
Upper
Non-
Critical
Upper
Critical
Upper
Non-
Recoverable
CPU1
Temp
degrees C 0.000 0.000 0.000 90.000 93.000 95.000
CPU2
Temp
degrees C 0.000 0.000 0.000 90.000 93.000 95.000
