Citrix ADC MPX
Health
attribute Unit
Lower
Non-
Recoverable
Lower
Critical
Lower
Non-
Critical
Upper
Non-
Critical
Upper
Critical
Upper
Non-
Recoverable
VBAT Volts 2.400 2.544 2.688 3.312 3.456 3.600
Health attributes for MPX 24100 platform
The following table lists the health attributes for MPX 24100/24150.
Health
attribute Unit
Lower
Non-
Recoverable
Lower
Critical
Lower
Non-
Critical
Upper
Non-
Critical
Upper
Critical
Upper
Non-
Recoverable
CPU1
Temp
degrees C 0.000 0.000 0.000 90.000 93.000 95.000
CPU2
Temp
degrees C 0.000 0.000 0.000 90.000 93.000 95.000
System
Temp
degrees C -9.000 -7.000 -5.000 80.000 85.000 90.000
Peripheral
Temp
degrees C -9.000 -7.000 -5.000 80.000 85.000 90.000
PCH
Temp
degrees C -11.000 -8.000 -5.000 90.000 95.000 100.000
FPC_Temp
1
degrees C - NA - - NA - - NA - 66.000 70.000 75.000
FPC_Temp
2
degrees C - NA - - NA - - NA - 72.000 76.000 82.000
FPC_Temp
3
degrees C - NA - - NA - - NA - 72.000 76.000 82.000
HDDBP_Temp
1
degrees C - NA - - NA - - NA - 72.000 76.000 82.000
HDDBP_Temp
2
degrees C - NA - - NA - - NA - 72.000 76.000 82.000
FAN 1 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
FAN 2 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
FAN 3 RPM - NA - 1980.000 - NA - - NA - - NA - - NA -
