Citrix ADC MPX
The Citrix ADC MPX 15000-50G FIPS certified appliance has the following ports:
• RS232 serial console port.
• One 10/100/1000Base-T RJ45 copper Ethernet LOM port. Use this port to remotely monitor and
manage the appliance independently of the Citrix ADC soware.
• Two 10/100/1000Base-T RJ45 copper Ethernet Management ports, numbered 0/1 and 0/2. This
port is used to connect directly to the appliance for Citrix ADC administration functions.
• Eight 10G SFP+ Ethernet ports, numbered 10/1 to 10/8.
• Four 50G ports, numbered 50/1 to 50/4. For information about supported transceivers per port,
see 25G, 40G, 50G, and 100G ports.
The following figure shows the back panel of the Citrix ADC MPX 15000-50G FIPS certified appliance.
Figure 2. Citrix ADC MPX 15000-50G FIPS certified appliance, back panel
