C
D
III
143
BOOT - LUGGAGECOVER BLIND - G RA N D C 4 P I C AS S O
Position 2 : (continued)
To remove the roller :
1. Push the flap towards the seat backrest.
2. Lift the concertina plate by grabbing it at the side,
then position it vertically.
3.
Unlock the seat by pulling the strap G (see « Third-row
rear seats »)
.
4. Push the backrest towards the front.
5. Proceed in reverse order to installing.
Note : you can position the concertina plate vertically
to lodge a bulkier object in the boot well.
Position 3 : (7-seat configuration, stowage
position)
To install the roller :
1. Remove the blind from its current position.
2. Position the roller, with the blind pull bar upper-
most, flap downward.
3. Engage the lug on the left of the roller in notch C.
4. Pass the right-hand side above the third-row armrest.
5. Engage the lug in notch D.
To remove the roller :
- Proceed in reverse order to installing.
