TABLE OF FUSES - FUSES UNDER THE BONNET
Engine compartment fuses
Fusebox
To access the fusebox located in
the engine compartment, detach
and remove the cover.
All work on the MAXI fuses, which are located in these fuseboxes
and which give extra protection, is the preserve of CITROËN technicians.
After any operation, carefully
reclose the cover. If the cover is
not correctly positioned or not
properly closed, that could cause
serious problems on your vehi-
cle. For the same reason, take
care not to spill any liquid in the
fusebox.
