II. SPECIAL FEATURES
- Clearance between pedal and brake-valve
” ..:
0.05 to 3 mm
_ Stoplamp switch ,: Inal/) VII/S/ lislli c/c .soo,~ 05 [I(‘~~II /~//c-/~c,s IJTO~(~ /,fl// (J
Main braking system :
- Diameter of disc
.......................................................................... 260 mm
- Thickness of disc ......................................................................... 20 mm
s Minimum thickness after wear
.................................................... 18 mm
_ Max run-out of disc ................................................................... 0 2 mm
- Diameter of operatinq pistons
.................................................... 42 mm
- Area of one pad
............................................................................ 55 cm2 (8 52sq.in)
- Thickness of lining on the pad .,,_.,..,_.__.._.._,....,.......................... 115mm
233 5 mm 235 mm
9 mm 18 mm
7 mm 16 mm
0.2 mm 0 2 mm
30 mm
40 mm
24 cm2 (3.72 (36cm2 (5.5
sq.in) sq.in
12 mm
12 mm
- Checking the flatness of a disc take a reading in 8 different points
the results should be the same to
within : 0.02 mm
TYPE OF BRAKE PAD LINING (Front linings incorporating warning-lamps leads j
AUTHORISED REPAIR FITTINGS
VEHICLE
All Snlow L’c~l,ir-ll 5
CX 2000 ( MA series MB )
CX 2200 ( MA series MC )
CX 2400 ( MA series MJ )
CX Prestiqe (MA series MK )
CX 2400 GTI ( MA series ME )
CX 2000 ( MA series MD )
CX 2400 ( MA series MF )
8
1
FRONT
REAR
TEXTAR- T .= 254 FERODO 748
or
FERODO e 748
I
FERODO 748
TEXTAR - T - 254 1 TEXTAR -T2-54
or
TEXTAR - T 254
I
FERODO - 748
or
FERODO - 748
I
FERODO r 748
