185
CLUTCH
GEARBOX
DRIVESHAFTS
BE4/5 GEARBOX
Engine : RFN
Tightening torques
Ref. Description Number of screws m.daN
1 End guide 3 1.2 ± 0.1
2 Clutch housing 13 1.3 ± 0.1
3 Primary shaft nut 1 7.2 ± 0.7
4 Secondary shaft nut 1 6.5 ± 0.7
5 Yoke holding screw 2 1.5 ± 0.1
6 Differential gearwheel screw 2 6.5 ± 0.7
Reverse gear contact 1 2.5 ± 0.3
7 Differential housing 4 5 ± 0.5
8 Breather pipe 1 1.7 ± 0.2
9 Rear housing cover screw 7 1.2 ± 0.1
10 Top-up plug 1 2.2 ± 0.2
11 Differential housing screw 4 1.2 ± 0.1
12 Drain plug screw 1 3.5 ± 0.4
SYNERGIE
B2CP3BSP
B2CP3BTD
