AXLES
SUSPENSION
STEERING
231
SYNERGIE
AXLE
GEOMETR
Y
CONDITIONS FOR ADJUSTING
THE HEIGHTS
(T
yre pressures
correctly set.)
Heights (mm)
Rear
Front
H1
161
166
T
yres
195/65R 15
205/65R 15
H2
166
171
The reference
heights
must be
checked between
the
jacking
points and
the
ground.
Front
Rear
T
racking
(T
oe-in/toe-out)
0°
mm
+0°8’
to +0°25’
+1 to
+3
Castor angle
max.
(left-right difference
:
30’)
3°30’
to ±
30’
Camber angle
King pin
(inclination)
0
°±3
0
’
1
1°28’
±
40’
-1°
±
30’
158
195/70R
14
163
B3BP051D
NOTE
PINCEMENT
TOE-OUT
-
=
+
=
A<
B
=
Positive figure
:
A>
B
=
Negative figure
:
B3BP051D
Reference height
237
