<Output Data List (EtherNet/IP Specifications) (1/2)>
AX (Output)  PLC
Byte bit Description Logic
0
0 M code output (bit 0) Positive
1 M code output (bit 1) Positive
2 M code output (bit 2) Positive
3 M code output (bit 3) Positive
4 M code output (bit 4) Positive
5 M code output (bit 5) Positive
6 M code output (bit 6) Positive
7 M code output (bit 7) Positive
1
0 In-position output Positive
1 Positioning completion output Positive
2 Start input wait output Positive
3 Alarm output 1 Negative
4 Alarm output 2 Negative
5 Output 1 during indexing / Home position output Positive
6 Output 2 during indexing / Servo state output Positive
7 Ready output Positive
2
0 Segment position strobe output Positive
1 M code strobe output Positive
2 to 7 Unavailable
3 - Unavailable
4
0 Monitoring Positive
1 Instruction code execution completion Positive
2 to 7 Unavailable
5 - Unavailable
6 - Unavailable
7 - Unavailable
8 -
Monitor data 1 Note 1
9 -
10 -
11 -
Note 1: A total of 4 bytes is handled as one piece of data.
The sequence of each byte data is little endian.
