<Output Data List (EtherNet/IP Specifications) (2/2)>
AX (Output)  PLC
Byte bit Description Logic
12 -
Monitor data 2 Note 1
13 -
14 -
15 -
16 -
Monitor data 3 Note 1
17 -
18 -
19 -
20 -
Response code Note 1
21 -
22 -
23 -
24 -
Read data Note 1
25 -
26 -
27 -
28 -
Unavailable
29 -
30 -
31 -
Note 1: A total of 4 bytes is handled as one piece of data.
The sequence of each byte data is little endian.
