CKD GPS3 Series - Page 13

c）Swarfandgrinderchips,etc.,couldclogthenozzle.Switchthesupplypressure
(max.600kPa)whentransportingtheworkpieceduringmachiningprocessesto
preventthedetectionnozzlefrombecomingclogged.
d）Selectanoutputformat(NPN,PNP)matchingtheinputunitoftheprogrammable
controllerbeingused.
e）OperationmaybedisabledifacapacitanceloadsuchasanAC/DCbuzzeris
connectedtotheload.Aprotectioncircuitisprovidedtopreventdamagefrom
incorrectwiringorovercurrent.Arelaymustbeusedwhenconnectinga
capacitanceload.
f)Usingthemastergaugeandgapgauge
・Becarefulnottobedangerousasitwillbeadjustedwhileoperatingthemachine.
 Adjustmentis1)gaugeset,2)machineoperation,3)adjustmentofthisproduct,
 atotalof3peoplearerequired.
・Clearancecannotbesetunlessthemastergaugeorgapgaugeisaccurately
 pressedagainstthedetectionnozzle.
g)Onedetectionnozzlecanbeusedforoneoftheseproductunits.
h）Immediatelyafterworkisstarted,thecoolantfromthenozzlemayaccumulatein
thepipeandcausethesensortoturnONforashorttime.Waitforcoolanttobe
dischargedbythedetectionairbeforestartingthemachine.
i）Ifthenozzlebecomesblocked,removethepipeonthisproduct'ssideandblowout
stuckforeignmatterwithanairgun.Ifforeignmattercannotberemoved,
pokeaneedle,etc.,throughthedetectionnozzleontheend.
j）Iftheoutputsettingvalueischanged,controlsystemdevicescouldoperate
unintentionally.
Stopdevicesbeforechangingsettings.
k）Ensureproperoperationthroughperiodicinspections.
CAUTION
PROPER
OPERATION
３
[SM-P00143-A] −12−
