WS1, 1.5 & 2 Series Watersoftener
Installation Operation Maintenance Manual
SIMPWS1 REV3 13/07/11 PAGE 21 OF27
11.2 ENGINEERING DATA
11.2.1 WS1 20-80 L
PARAMETER UNITS 25L 30L 40L 50L 60L 80L
VESSEL SIZE INCH 9x35 10x35 10x44 10x54 12x48 13x54
BRINE TANK
HEIGHT
MM 960 960 960 1040 1040 1040
BRINE TANK WIDTH MM 285 285 370x
430
480 480 480
TOTAL HEIGHT MM 1100 1100 1340 1590 1440 1590
REAR CLEARENCE
REQUIRED
MM 50 50 50 50 50 50
INLET CONNS INCH 1 1 1 1 1 1
OUTLET CONNS INCH 1 1 1 1 1 1
DRAIN CONNS INCH ¾ ¾ ¾ ¾ ¾ ¾
BREIN TANK
OVERFLOW
INCH ½ ½ ½ ½ ½ ½
DELIVERED
WEIGHT
KG 19 20 21 23 25 30
ELECTRICAL
POWER 240 V 50 HZ
V/A 1.2 1.2 1.2 1.2 1.2 1.2
IMPORTANT NOTES
MAXIMUM OPERATING PRESSURE 5.5 BARG MINIMIUM OPERATING PRESSURE 1.7 BARG
HEADROOM ALLOW 100MM GREATER THAN THE OVERALL HEIGHT.
