Clack WS2 series User Manual

WS1”, 1.5” & 2” Series Watersoftener
Installation Operation Maintenance Manual
SIMPWS1 REV3 13/07/11 PAGE 23 OF27
11.2.3 WS1.5 100-500 L
PARAMETER UNITS 100 120 150 250 350 500
VESSEL SIZE INCH 14x65 14x65 16x65 21x62 24x72 30x72
BRINE TANK
HEIGHT
MM 1040 1040 950 900 1100 1250
BRINE TANK WIDTH MM 480 480 700 840 880 1250
TOTAL HEIGHT MM 1984 1984 1988 2038 2225 2450
REAR CLEARENCE
REQUIRED
MM 50 50 50 50 50 50
INLET CONNS INCH 1.5 1.5 1.5 1.5 1.5 1.5
OUTLET CONNS INCH 1.5 1.5 1.5 1.5 1.5 1.5
DRAIN CONNS INCH ¾ ¾ ¾ ¾ ¾ ¾
BREIN TANK
OVERFLOW
INCH ½ ½ ½ ½ ½ ½
DELIVERED
WEIGHT
KG 115 130 170 280 380 500
ELECTRICAL
POWER 240 V 50 HZ
V/A 1.2 1.2 1.2 1.2 1.2 1.2
IMPORTANT NOTES
MAXIMUM OPERATING PRESSURE 5.5 BARG MINIMIUM OPERATING PRESSURE 1.7 BARG
HEADROOM ALLOW 100MM GREATER THAN THE OVERALL HEIGHT.

Clack WS2 series Specifications

General

Model Series	WS2
Pressure Rating	125 PSI
Metered	Yes
Time Clock	Yes
Regeneration Type	Downflow or Upflow
Cycle Adjustment	Yes
Materials of Construction	Noryl
Type	Water Softener
Flow Rate	12 GPM
Control Valve	Fleck 5600
Valve Size	1"
