3 CMS5
CMS5 4
DISPLAY CONTROLLER BUTTONS
Previous Song
Seek Back
Play/Pause
Back
Previous Screen
Next Song
Seek Forward
Source
Main Menu
Volume
Option Scroll
Enter Selection
Mute/Unmute
Volume Knob
Functions:
Rotate Volume Knob = Adjust Volume Level (Play Screens).
Press in & Release Volume Knob = Mute/Unmute (Play Screens).
Rotate Volume Knob = Scroll Through Options (Menus).
Press in & Release Volume Knob = Select/Enter (Menu Options).
Options Arrow
This double sided arrow will only appear when additional options are available.
CAUTION
When the unit is turned ON, and the volume has been increased to the maximum level:
May cause damage to your hearing.
Please be aware and cautious of the volume level at all times.
OFF
1.
Press and Hold the Power Button for 3-seconds[ ]
2. The Blue LED trim around the Volume Knob will turn OFF
- System in Powering Down Screen (5 Seconds)
- Clarion Splash Screen (10 Seconds)
TURNING SYSTEM ON AND OFF
Power
ON / OFF
Display Options
Audio Settings
Menu Options
Favorites
Note:
- Start the engine before using this unit.
- Be careful about using this unit without the engine running. If used for long periods of time without the engine
running to charge the batteries, you may not be able to start the engine and this can Reduce the life and
ON
1. Start the engine. (Accessory Battery Switch ON)
2.
The CMS5 will automatically Power ON
3. The Blue LED trim around the Volume Knob will light up and the CMS5 Display Controller
- Clarion Splash Screen (10 Seconds)
- Viewing Video Disclaimer (5 Seconds)
4. Press and Release the Power Button to turn ON or OFF the unit
*
If the CMS5 does not Power ON when the vessel is started, Press and Release the Power Button [ ]
performance of the batteries. A Warning will appear when voltage is 10V or below.
- The audio will stop until voltage increases to 10.4v or above, then the audio will resume. This will
help from draining too much current from the battery until the voltage increases.
