Clarion CZ501E User Manual

English
11
At all mode, press and hold [D] button to
enter system setup. Press [ ] or [ ]
button to select options, rotate the [VOLUME]
knob to adjust.
AF:ON/OFF(RADIOmode)
Rotate the [VOLUME] knob to choose AF ON
or OFF.
REG:ON/OFF(RADIOmode)
Rotate the [VOLUME] knob to choose REG
ON or OFF.
DX/LO(RADIOmode)
Rotate the [VOLUME] knob to choose radio
local or distant at RADIO mode.
• LO: Only stations with strong signal can
be received.
• DX: Stations with strong and weak signals
can be received.
AUXSENS(AUXmode)
Rotate the [VOLUME] knob to choose AUX
Input sensitivity LOW, MID or HIGH at AUX
mode.
PIN CODE
Rotate and press the [VOLUME] knob to
choose a 4-digit password. Press the knob
more than 1 second to conrm.
SCRNSVR:ON/OFF
Rotate the [VOLUME] knob to choose SCRN
SVR (screen saver) ON or OFF.
SCROLL: ON/OFF
For track information that is longer than the
display panel:
When SCROLL is ON, the LCD will display
System Setup
ID3 TAG information cyclely, e.g: TRACK-
> F O L D E R - > F I L E - > A L B U M - > T I T L E -
>ARTIST->TRACK->...
When SCROLL is OFF, the LCD will display
one of the ID3 TAG information, the default
is TRACK, but user can adjust it to other ID3
TAG information by press [DISP] button.
S-CTRL(IPODmode):ON/OFF
Rotate the [VOLUME] knob to choose S-CTRL
(Simple Control) ON or OFF.
* Refer to P17.
SW PHASE
Rotate the [VOLUME] knob to choose SUB-
WOOFER phase REVERSE or NORMAL.
DIMMER: ON/OFF
Rotate the [VOLUME] knob to choose
DIMMER ON or OFF.
• ON: LCD dimmer is active when small light
of vehicle is turned ON.
• OFF: LCD always maximum brightness
regardless of the vehicle small light.
BEEP: ON/OFF
Rotate the [VOLUME] knob to choose button
beep sound ON or OFF.
MICSEL(BTmode)
Rotate the [VOLUME] knob to choose
Microphone EXTERNAL or INTERNAL.
MICGAIN(BTmode)
Rotate the [VOLUME] knob to choose Mic
gain: 1, 2, 3, 4, 5.
You can change the gain of MIC when a
telephone partner cannot hear your voice.
Press the [SOUND] button to enter sound
effect setting mode. First press shows current
EQ. Rotate the [VOLUME] knob to changes
BEAT EQ in this order:
OFF -> B-BOOST -> IMPACT -> EXCITE ->
CUSTOM
Rotate the [VOLUME] knob to changes
CUSTOM, and press the [VOLUME] knob,
the press [
] or [ ] button to select
it including: BAS-G -> BAS-F -> BAS-Q
-> MID-G -> MID-F -> MID-Q -> TRE-G ->
TRE-F, rotate the [VOLUME] knob to select a
Audio Setup
value.
BAS-G / MID-G / TRE-G: (-7)- (+7)
BAS-F: 50/100/200
BAS-Q: 0.7/1/1.4/2
MID-F: 500/1K/2K
MID-Q: 0.7/1/1.4/2
TRE-F: 5k/10k/15k
TRE-Q 0.7/1.0/1.4/2.0
Press the [SOUND] button, then press [ ]
or [ ] button to select USER preset
including:
BALANCE -> FADER -> M-B EX -> LPF(low
Downloaded from Caradio-Manual.com Manuals
