29
•Connectingtotheexternalamplier
External ampliers can be connected to the 4 channel RCA output connections.
Ensure that the connectors are not grounded or shorted to prevent damage to the
unit.
8) ConnectingtheAccessories
For VW and Audi: Change wiring like above.
A
B
C
16
14
12
10
8
6
4
2
15
13
11
9
7
5
3
1
1
3
5
7
2
4
6
8
1
3
5
7
2
4
6
8
Rear right -
Front right -
Front left +
Rear left +
Remote on
ACC +
Ground
Rear right +
Front right +
Front left -
Rear left -
Illumination
Phone Mute
Battery +
Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Front right (+) / Gray
Battery 12V(+) / Yellow
Front right (-) / Gray with black stripe
Remote On / Blue with white stripe
Front left (+) / White
Illumination / Orange with white stripe Front left (-) / White with black stripe
ACC+ / Red Rear left (+) / Green
Ground / Black Rear left (-) / Green with black stripe
YellowYellow
Red Red
Function
ConnectorA ConnectorB
Location
