Clarion NX702 Installation Manual

English
26
NX702
1. Insert an USB device into the USB cable.
When connecting an USB device, the unit
YKNNTGCFVJGſNGUCWVQOCVKECNN[
2. To remove the USB device, you should
first select another source or turn off
VJGRQYGTKPQTFGTVQCXQKFFCOCIKPI
the USB device. Then take off the USB
device.
3. To access an USB device already
connected to the unit, long press [ MENU
ALL ] button to enter main source menu,
then select [USB] to enter USB mode.
If [USB] is not on the current source menu,
touch [] buttons on the bottom of the
screen, or hold the center of screen and
FTCINGHVTKIJVVQUJQYOQTGKEQPU
1. Press [OPEN?DWVVQPVQUNKFGFQYPVJG
panel. Insert an SD card into the card slot
located on the left side of the panel.
9JGPKPUGTVKPICECTFVJGWPKVYKNNTGCF
VJGſNGUCWVQOCVKECNN[
 6QTGOQXGVJGECTF[QWUJQWNFſTUVUGNGEV
CPQVJGTUQWTEGQTVWTPQHHVJGRQYGTKP
order to avoid damaging the card. Press to
pop it out, then take off the card. Close the
panel.
3. To access an SD card already inserted in
the unit, long press [ MENU
ALL ] button
to enter main source menu, then select
[SD] to enter SD mode.
If [SD] is not on the current source menu,
touch [] buttons on the bottom of the
screen, or hold the center of screen and
FTCINGHVTKIJVVQUJQYOQTGKEQPU
Accessing an USB
Accessing an SD Card
8. SD/USB OPERATION

Clarion NX702 Specifications

General

MP3 playback	Yes
CD-RW playback	-
Audio formats supported	MP3, MP4, WMA
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, DUN, HFP, HSP, OPP, PBAP
Line outputs (RCA)	6
USB ports quantity	1
DIN size	2 DIN
Output power	200 W
Product color	Black
Disc types supported	CD, CD-R, DVD
Audio output channels	4.0 channels
Maximum power per channel	50 W
Supported radio bands	AM, FM
Display diagonal	7 \
Compatible memory cards	MicroSD (TransFlash)
