Clarion PH-2761C-F User Manual

929-5000-80
- M3 -
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 ----------- SENSOR PWB 1
2 ----------- MAIN PWB 1
3 SMA-182-100 SPINDLE MOTOR-ASSY 1
4 SMA-183-100 SLED MOTOR-ASSY 1
5 345-5476-20 CUSHION RUBBER 1
6 620-1023-23 CLAMPER PLATE 1
7 620-1026-21 SPRING PLATE 1
8 620-1596-23 CLAMPER LINK 1
9 620-1598-22 UPPER CHASSIS 1
10 620-1752-20 SENSOR ARM 1
11 620-1753-20 ID-LOCK PLATE 1
12 620-1754-20 LOWER CHASSIS 1
13 621-0608-21 SECOND GEAR 1
14 621-0609-20 BASE GEAR 1
15 621-0610-20 IDLE GEAR A 1
16 621-0611-20 IDLE GEAR B 1
17 621-0612-21 ROLLER GEAR A 1
18 621-0620-20 THREAD GEAR A 1
19 621-0621-20 THREAD GEAR B 1
20 621-0623-23 LS-HOLDER 1
21 621-0624-22 GUIDE RAIL 1
22 621-0711-20 LOADING ROLLER 2
23 621-0718-21 ROLLER GUIDE 1
24 621-0719-20 ROLLER GEAR B 1
25 621-0720-20 ROLLER GEAR C 1
26 621-0721-20 ROLLER GEAR D 1
27 621-0728-20 STOPPER LINK 1
28 621-1719-20 IDLE CASE 1
29 621-1726-20 ROLLER SLEEVE 2
30 621-1729-20 SH-BASE 1
31 621-1742-20 UPPER GUIDE 1
32 621-1743-20 SHIFT LEVER 1
33 621-1744-20 RACK 1
34 621-1745-20 LOCK ARM L 1
35 621-1746-20 LOCK ARM R 1
36 621-1747-20 GEAR COVER 1
37 621-1748-20 POWER GEAR A 1
38 621-1749-20 POWER GEAR B 1
39 621-1750-20 POWER GEAR C 1
40 621-1751-20 POWER GEAR D 1
41 621-1752-20 DISC STOPPER 1
42 621-1753-20 CLAMPER RING 1
43 621-1754-20 GEAR BASE 1
44 622-1571-21 ROLLER SHAFT 1
45 624-0020-00 LEAD SCREW 1
46 629-0086-20 DAMPER F 2
47 629-0087-20 DAMPER R 1
48 716-1507-01 SCREW(M2x3) 3
49 716-1670-01 SCREW(M2x4) 4
50 716-1733-01 SCREW(M1.7x2.3) 2
51 716-3469-01 SCREW(1.7x4) 2
52 716-3473-01 SCREW(M2x3) 1
53 716-3551-00 SCREW(M1.4x2.5) 2
54 750-3467-21 SHIFT SPRING 1
55 750-3468-20 RACK SPRING 1
56 750-3469-20 CLAMPER SPRING 1
57 750-3470-20 ID-LOCK SPRING 1
58 750-3471-20 SENSOR SPRING 1
59 750-3472-21 DR-SPRING F 2
60 750-3473-20 DR-SPRING RA 1
61 750-3474-20 DR-SPRING RB 1
62 750-3475-21 DR-SPRING C 1
63 750-6797-20 ROLLER SPRING L 1
64 750-6798-20 ROLLER SPRING R 1
65 714-2003-8B SCREW(M2x3) 2
66 780-2025-00 SCREW(M2x2.5) 3
67 781-1730-00 SCREW(M1.7x3) 1
68 803-4906-60 VINYL-COAT-WIRE(ORG) 1
69 816-2542-01 FLAT WIRE 1
70 816-2590-00 VINYL-COAT-WIRE(GRN) 1
71 816-2591-00 VINYL-COAT-WIRE(YEL) 1
72 816-2592-00 VINYL-COAT-WIRE(BLUE) 1
73 816-2593-00 VINYL-COAT-WIRE(PUR) 1
74 966-1722-20 SH-RACK-ASSY 1
75 966-1743-21 DRIVE-PLT-ASSY 1
76 969-0071-30 PICKUP-ASSY 1
