Clarion PH-2761C-F User Manual

929-5000-80
- M4 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
CD PWB(BM1) section
C1 168-1042-78 16V 0.1uF
C2 163-1073-35 16V 100uF
C4 178-1052-78 1uF
C5 042-0560-85 6.3V 100uF
C6 178-1052-78 1uF
C8 178-1052-78 1uF
C10 168-1042-78 16V 0.1uF
C11 168-1042-78 16V 0.1uF
C12 045-4701-50 47pF
C13 046-1532-78 0.015uF
C14 168-1042-78 16V 0.1uF
C15 046-1032-78 0.015uF
C17 046-4722-58 4700pF
C18 046-1522-58 1500pF
C19 168-1042-78 16V 0.1uF
C20 168-1042-78 16V 0.1uF
C21 046-6812-58 680pF
C22 168-1042-78 16V 0.1uF
C23 046-1532-78 0.015uF
C24 168-1042-78 16V 0.1uF
C25 045-6801-50 68pF
C26 168-1042-78 16V 0.1uF
C27 046-3332-78 0.033uF
C29 046-6822-58 6800pF
C30 168-1042-78 16V 0.1uF
C31 046-4712-58 470pF
C32 046-4712-58 470pF
C33 168-1042-78 16V 0.1uF
C34 168-4732-78 16V 0.047uF
C35 168-4732-78 16V 0.047uF
C36 045-1007-50 10pF
C37 045-1007-50 10pF
C38 168-1042-78 16V 0.1uF
C39 046-5622-58 5600pF
C40 168-1042-78 16V 0.1uF
CCT1 050-0140-63 1/32W 47k ohm x4J
D1 001-0367-91 1SS226
IC1 051-6079-90 BA5830FPG
IC2 051-6399-00 TC94A15F
J101 074-1228-79 29P
J201 074-1138-65 15P
J301 074-1138-60 10P
Q1 131-1188-50 2SB1188PQR
R1 117-6811-15 1/8W 680 ohm
R2 117-1001-15 1/8W 10 ohm
R3 033-2211-15 1/10W 220 ohm
R5 033-0000-05 1/10W 0 ohm
R6 033-5621-15 1/10W 5.6k ohm
R7 033-4731-15 1/10W 47k ohm
R8 033-3341-15 1/10W 330k ohm
R9 033-2231-15 1/10W 22k ohm
R10 033-2231-15 1/10W 22k ohm
R11 033-2731-15 1/10W 27k ohm
R12 033-4731-15 1/10W 47k ohm
R13 033-2731-15 1/10W 27k ohm
R14 033-1531-15 1/10W 15k ohm
R15 033-2731-15 1/10W 27k ohm
R16 033-8231-15 1/10W 82k ohm
R17 033-2731-15 1/10W 27k ohm
R18 033-8231-15 1/10W 82k ohm
R19 033-1051-15 1/10W 1M ohm
R20 119-2221-15 1/10W 2.2k ohm
X2 061-3534-90 16.92MHz
PWB 039-2741-20 PWB(WITHOUT
COMPONENT)
Sensor PWB(BM2) section
D1 001-7058-90 AN1105W-RR
D2 001-7058-90 AN1105W-RR
J1 074-1138-60 10P
Q1 060-4015-91 PS1192HB
Q2 060-4015-91 PS1192HB
S1 013-7414-50 CHUCKING
S2 013-7413-50 LIMIT
PWB 039-2675-20 PWB(WITHOUT
COMPONENT)
