Clarion PN-2940S-A User Manual

PN-2940S-A,
S-B,C,D,E,F
- 6 -
ELECTRICAL PARTS LIST
Main PWB(B1) section
C1 042-0643-56 16V 470uF M
C2 042-0643-56 16V 470uF M
C3 043-0554-90 25V 10uF
C4 166-1011-50 100pF CH
C9 168-1032-55 0.01uF K
C10 178-1052-78 1uF
C11 042-0643-58 6.3V 330uF
C12 168-1045-56 0.1uF Z
C13 042-0643-57 16V 220uF
C14 178-1052-78 1uF
C15 043-0568-90 25V 2.2uF
C16 178-1052-78 1uF
C17 163-4763-15 6.3V 47uF
C18 163-4763-15 6.3V 47uF
C19 166-1021-50 1000pF CH
C21 166-1021-50 1000pF CH
C22 178-1052-78 1uF
C23 166-1021-50 1000pF CH
C24 168-2232-55 0.022uF K
C25 166-1011-50 100pF CH
C26 168-1045-56 0.1uF Z
C27 168-1032-55 0.01uF K
C28 163-1063-35 16V 10uF
C29 168-1045-56 0.1uF Z
C31 168-6832-78 0.068uF K
C32 166-1011-50 100pF CH
C33 163-1053-65 50V 1uF
C34 166-1011-50 100pF CH
C35 168-1045-56 0.1uF Z
C36 168-1045-56 0.1uF Z
C37 166-1011-50 100pF CH
C38 168-1032-55 0.01uF K
C39 043-0552-90 6.3V 47uF M
C40 166-1011-50 100pF CH
C41 168-1042-78 16V 0.1uF
C42 168-1022-55 1000pF K
C44 168-1045-56 0.1uF Z
C45 168-1045-56 0.1uF Z
C46 166-1011-50 100pF CH
C47 168-1042-78 16V 0.1uF
C48 166-1501-50 15pF CH
C51 168-1042-78 16V 0.1uF
C52 168-1042-78 16V 0.1uF
C356 166-5611-50 560pF CH
CCT1 050-0140-67 1/32W 220 ohm x4J
CCT3 050-0140-67 1/32W 220 ohm x4J
CCT4 050-0140-55 1/32W 2.2k ohmx4J
CCT5 050-0140-67 1/32W 220 ohm x4J
CCT6 050-0140-67 1/32W 220 ohm x4J
CCT7 050-0140-67 1/32W 220 ohm x4J
CCT8 050-0140-63 1/32W 47k ohm x4J
CCT9 050-0140-67 1/32W 220 ohm x4J
CCT10 050-0140-63 1/32W 47k ohm x4J
CCT11 050-0140-63 1/32W 47k ohm x4J
CCT12 050-0140-67 1/32W 220 ohm x4J
CCT13 050-0140-63 1/32W 47k ohm x4J
CCT17 050-0140-63 1/32W 47k ohm x4J
CCT18 050-0140-63 1/32W 47k ohm x4J
D1 001-2015-00 RL253
D2 001-4100-38 PTZ36
D3 001-1304-90 DAN202U
D4 001-2403-90 M1F60
D5 001-4100-50 PTZ TE25 9.1B
D6 001-0529-32 MA8056-M
D7 001-4100-38 PTZ36
D8 001-0529-32 MA8056-M
D9 001-0516-90 MA111
D10 001-0516-90 MA111
D11 001-0516-90 MA111
D12 001-4100-38 PTZ36
D14 001-2403-90 M1F60
D15 001-0529-20 MA8039-L
D303 001-0516-90 MA111
FIL4 060-3113-95 NFM2012R13C102R
IC1 051-7243-18 TC7SET08FU-
TE85L,F
IC4 051-3344-90 BD3930FP-E2
IC5 051-3388-90 NJM2887DL3-TE1
IC6 051-5452-90 BD5235G-TR
IC7 ----------- BR93L56RFVM-W
IC8 051-5445-08 BD5227G-TR
IC9 052-5075-00 M30302MAP-A44GP
J1 074-2015-60 60P
J3 074-4011-24 OUTLET SOCKET
L3 010-3104-50 30 ohm/100MHz
L4 010-3105-69 80 ohm/100MHz
L102 010-3604-90 ZJYS51R5-2PB
Q3 125-2027-91 DTC114EUA
Q4 125-0021-91 DTA114EUA
Q5 103-2353-00 2SD2353
Q6 192-3325-00 2SC3325
Q7 190-1313-00 2SA1313 O,Y
Q8 192-4116-50 2SC4116 Y,G
Q9 133-1766-00 2SD1766
Q10 190-1586-50 2SA1586 Y,G
Q11 125-2027-91 DTC114EUA
Q12 125-2027-91 DTC114EUA
Q13 125-0021-91 DTA114EUA
Q14 131-1188-00 2SB1188
Q15 192-4116-50 2SC4116 Y,G
Q16 192-4116-50 2SC4116 Y,G
Q17 125-2027-91 DTC114EUA
Q22 193-1819-50 2SD1819AR,SL
Q30 125-2027-91 DTC114EUA
Q31 125-2027-91 DTC114EUA
Q32 131-1188-00 2SB1188
Q302 131-1188-00 2SB1188
Q313 125-2027-95 DTC143ZU
R9 116-3901-15 1/4W 39 ohm
R10 116-3901-15 1/4W 39 ohm
R13 116-3901-15 1/4W 39 ohm
R14 116-3901-15 1/4W 39 ohm
R15 119-1041-15 1/10W 100k ohm
R16 116-2711-15 1/4W 270 ohm
R17 032-0140-88 1/10W 100k ohm F
R18 032-0140-03 1/10W 220k ohm F
R19 119-0000-05 1/10W 0 ohm JW
R20 116-2401-15 1/4W 24 ohm
R24 119-1031-15 1/10W 10k ohm
R26 119-2711-15 1/10W 270 ohm
R27 119-2211-15 1/10W 220 ohm
R28 119-2231-15 1/10W 22k ohm
R30 119-5621-15 1/10W 5.6k ohm
R31 119-5631-15 1/10W 56k ohm
R32 119-4711-15 1/10W 470 ohm
R33 119-5631-15 1/10W 56k ohm
R34 119-1031-15 1/10W 10k ohm
R35 119-1021-15 1/10W 1k ohm
R36 119-1031-15 1/10W 10k ohm
R37 119-1031-15 1/10W 10k ohm
R38 119-1521-15 1/10W 1.5k ohm
R39 119-1031-15 1/10W 10k ohm
R40 119-5631-15 1/10W 56k ohm
R41 119-4731-15 1/10W 47k ohm
R42 119-1031-15 1/10W 10k ohm
R47 032-0140-96 1/10W 120k ohm F
R48 032-0140-88 1/10W 100k ohm F
R49 119-1041-15 1/10W 100k ohm
R50 116-3321-15 1/4W 3.3k ohm
R51 119-1031-15 1/10W 10k ohm
R52 119-1031-15 1/10W 10k ohm
R53 119-1041-15 1/10W 100k ohm
R54 119-1041-15 1/10W 100k ohm
R55 119-5611-15 1/10W 560 ohm
R56 119-1031-15 1/10W 10k ohm
R57 119-2221-15 1/10W 2.2k ohm
R58 119-4731-15 1/10W 47k ohm
R60 119-4731-15 1/10W 47k ohm
R61 119-0000-05 1/10W 0 ohm JW
R62 119-1041-15 1/10W 100k ohm
R63 119-1041-15 1/10W 100k ohm
R64 119-2211-15 1/10W 220 ohm
R65 119-2211-15 1/10W 220 ohm
R66 119-0000-05 1/10W 0 ohm JW
R68 119-0000-05 1/10W 0 ohm JW
R71 119-0000-05 1/10W 0 ohm JW
R73 119-2721-15 1/10W 2.7k ohm
R74 119-2721-15 1/10W 2.7k ohm
R75 119-4721-15 1/10W 4.7k ohm
R82 119-0000-05 1/10W 0 ohm JW
R83 119-0000-05 1/10W 0 ohm JW
R90 119-1021-15 1/10W 1k ohm
R91 119-1031-15 1/10W 10k ohm
R92 119-4731-15 1/10W 47k ohm
R352 116-1091-15 1/4W 1 ohm
R354 119-2221-15 1/10W 2.2k ohm
R355 119-2221-15 1/10W 2.2k ohm
R358 119-1031-15 1/10W 10k ohm
T1 009-0679-00 CHOKE 0.53mH
TH301 002-0229-00 PTH8L05BAIR8M1B
TM1 073-0762-90 TERMINAL
TM2 073-0768-90 TERMINAL
TM3 073-0762-90 TERMINAL
TM4 073-0768-90 TERMINAL
TM5 073-0762-90 TERMINAL
X1 060-1533-90 CSTCE10M0G52-
RO
PWB 039-2974-00 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
