Page 22 - MS5500 Installation Manual
You can use this chart to quickly identify and interpret the MS5500 system’s chirp indications and
LED flashes.
Reference Chart
1 chirp arming normal arming
1 + 3 chirps arming Logic Sensor II sensitivity is off
1 + 4 chirps arming door, hood, or trunk is open
Double chirps while armed system triggered
(Passive Arming Entry Delay)
Output When Status
2 quick chirps arming Valet Mode is on
LED double flashes Valet Mode Starter Defeat Activated
2 chirps disarming normal disarming
1 long chirp disarming Tamper Alert - system was triggered
no chirps after Tamper Alert ignition
1 chirp after Tamper Alert door
2 chirps after Tamper Alert Logic Sensor II
3 chirps after Tamper Alert optional sensor
4 chirps after Tamper Alert hood or trunk
no LED flashes after Tamper Alert ignition
1 LED flash after Tamper Alert door
2 LED flashes after Tamper Alert Logic Sensor II
3 LED flashes after Tamper Alert optional sensor
4 LED flashes after Tamper Alert hood or trunk
1 chirp while armed Warn Away
5 quick chirps while armed Dedicated Remote Start Mode
activated
3 quick chirps while armed Logic Sensor II Defeat activated
Double chirps 1 minute after disarming Automatic Rearming
(for 10 seconds)
LED flashing quickly ignition key off Passive Arming sequence started
Two chirps ignition key off Full Time System Diagnostics
1 LED flash after Full Time Sys. Diag. door
2 LED flashes after Full Time Sys. Diag. Logic Sensor II
3 LED flashes after Full Time Sys. Diag. optional sensor
4 LED flashes after Full Time Sys. Diag. hood or trunk
