Main Unit
The main unit should be mounted in the interior of the vehicle. Do not mount the main unit
in the engine compartment. For maximum security, avoid mounting the main unit where it
will be easily accessible to a thief.
If you are mounting the unit under the dash board, be sure to mount the unit as high as
possible and in a location where it will not interfere with the operation of the pedals.
Be sure to extend the antenna as high as possible so that optimum range can be achieved.
Before securing the unit, be sure that you have made all of the necessary jumper selections
and perform a thorough function test of the system.
The case of the MS5500 is designed to be mounted using screws, or secured using wire
ties through the wire tie mounting tabs on the bottom of the unit as shown below.
Siren
Mount the siren facing downward and away from sources of heat and face the opening
downward to prevent water from collecting inside the housing. Be sure that the wires are
not easily accessible from underneath the vehicle.
For maximum security, it is best to disguise all under hood system wires with factory style
split loom tubing so that they cannot be easily identified by a thief.
Run all wires from the engine compartment into the interior of the vehicle through a
grommet.
Mounting Components
