MS5500 Installation Manual - Page 23
Door Lock Diagrams
Negative Trigger
Positive Trigger Voltage Reversal
Aftermarket Actuators Vacuum Lock System
White/green = (-) Lock / +12v Unlock
White/blue = (-) Unlock / +12v Lock
installation_MS5500.qxd 12/6/99 11:59 AM Page 23
