MS5500 Installation Manual - Page 5
Mounting For Shock
and Motion Sensitivity
Mounting For
Shock Sensitivity Only
Motion Sensitivity
Front/Rear
Side to Side
Position
Best
Best
Good
Least
Least
Good
Good
Good
Override Switch
Mount the Override Switch in a location near the driver where it is easily accessible but not
plainly visible. Plug the blue override switch connector into the blue 2-pin socket on the
main unit.
Be sure that the switch cannot accidentally be pressed or damaged by movement of
passengers or contents within the vehicle.
LED Status Indicator
Mount the status LED so that it is visible from both sides of the vehicle. Plug the white
LED connector into white 2-pin socket on the Main Unit.
installation_MS5500.qxd 12/6/99 11:59 AM Page 5
