Key Switch
• Connects the battery with all truck operating systems (drive, lift,
and steer electrical circuits) including the horn.
• Connects battery to the diagnostic display.
The key must always be inserted (in the ON position) to operate the
truck. When the key is removed (in the OFF position), instruments,
drive and pump motor electrical circuits are disconnected (shut-o).
The horn will not operate if the key switch is removed.
Control Handle
• Controls travel direction and speed, lift, horn, braking and steering.
• Twist grip or buttery type speed control for left or right hand
operation.
• Up or down brake application.
• Safety reversing switch on end of control handle.
• 180º rotation for maneuverability.
• Oset steering provides greater visibility for the operator.
Drive Unit
• 24-Volt DC drive motor.
Brakes
• Electronic magnetic parking brake provides safe and secure hold-
ing power.
Operator Controls
Common Truck
