4. Grip the flange and draw the side
filters from the side of the unit.
5. Wash the air filters gently in warm
water with a mild detergent. Rinse
the filters and dry them gently out
of direct sunlight.
• Make sure the filters are dry
before use.
6. Slide all the filters back into
position, side filters first, noting that
the top of the upper side filter is
curved and that the rear filters are
marked, ‘UP’ and ‘DOWN’.
STORAGE
1. If the appliance is not going to be used for some time, remove the drain
cap/plug and ensure all the water is removed.
2. Operate the unit in FAN mode at low speed until the drain outlet is dry. This
will discourage the growth of mould inside the unit.
3. Switch off the unit and disconnect the power cable. Coil it around the
hooks at the back of the machine and set the plug in the socket provided.
4. Remove and contract the exhaust duct and store it carefully.
• The duct must be disconnected by releasing the C-clamp which holds it in
place.
5. Remove the batteries from the remote control to prevent damage caused
by leakage.
6. Cover the unit and store it in a dry location.
FAULT CODES
The following fault codes can be displayed on the control panel.
Fault Code Diagnosis of Fault Action Required
E1 Piping temperature is
abnormal
Return to Clarke Service Department to
check coil temperature sensor or circuit
E2 Room temperature
sensor.
Return to Clarke Service Department to
check room temperature sensor circuit
E4 Anti-freezing protection Waiting for defrosting, function will
recover automatically.
