18
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
TECHNICAL SPECIFICATIONS
69 Indoor temp sensor fixing 73 Circular connector
70 Evaporator coils 74 Exhaust duct
71 Capillary tube 75 Duct connector
72 Return tube 76 Window installation panel
Power Supply 230V/50Hz
Weight 22.9 kg
Dimensions (L x W x H) 352 x 300 x 756 mm
Water Holding Capacity 0.35 L
Air Flow Volume
350 m
3
/h
Operating Temperature
10 - 35
o
C
Exhaust Duct Diameter 135 mm ID
Exhaust Duct Length (expanded) 1500 mm
Permissible Excessive Operating Pressure
(suction/discharge)
1.5 Mpa/4.0 MPa
Max Pressure (Low/High Pressure Side) 2.0 Mpa/5.5MPa
Sound Pressure Level Under 70 dB LpA
Sound Power Level 56 dB LwA
Energy Efficiency 2.61 (EU Class A)
Energy Consumption 0.8 kW/60min
Cooling Output 2.05 kW
Electrical Insulation Class 1
Energy Efficiency rate (EER) 2.6
REFRIGERANT DATA
This product contains hemetically seald flourinated greenhouse gasses,
Type R410A
Volume 400 g
GWP 2088
Co
2
Equivalent
0.835 t
PART NO DESCRIPTION PART NO DESCRIPTION
