EN
ENGLISH
- 6 - FORM NO. 70880A Clarke
®
Operator's Manual (EN) - CFP Polisher
Machine Specifi cations
Model CFP 130
Part Number 01281A
Voltage (Volts) 120
Frequency (Hz) 60
Current (Amps) 12.6
Pad /Brush Speed 175 rpm
Pad/Brush Size 13” (33 cm)
Power 1 hp (0.75 kW)
Gearbox 2 - Planet
Cord Length 50’ (15 m)
Handle Tube Tubular Steel
Main Frame Die Cast Aluminum
Height w/handle 46” (117 cm)
Weight w/cord 81 lbs. (36.8 kg)
Model CFP 170 CFP 170 CFP 1700 CFP 1700 CFP 1700 DS
Part Number 01280A 01310A 01320A 01350A 01431A
Voltage (Volts) 120 230 120 230 120
Frequency (Hz) 60 50 60 50 60
Current (Amps) 12.6 6.8 15 8.3 15/15
Pad /Brush Speed 175 rpm 145 rpm 175 rpm 145 rpm 180/320 rpm
Pad/Brush Size 17” (43 cm)
Power 1 hp 1.5 hp 0.9 / 1.5 hp
Gearbox 2 - Planet 3-Planet
Cord Length 50’ (15 m)
Handle Tube Tubular Steel
Main Frame Die Cast Aluminum
Height w/handle 46” (117 cm)
Weight w/cord 83 lbs. (37.7 kg) 91 lbs. (41.1 kg) 77 lbs. (35 kg)
Model CFP 200 CFP 200 CFP 2000 CFP 2000 CFP 2000 DS
Part Number 01360A 01390A 01400A 01401A 01430A
Voltage (Volts) 120 230 120 230 120
Frequency (Hz) 60 50 60 50 60
Current (Amps) 12.6 6.8 15 8.5 15 / 15
Pad/Brush Speed 175 rpm 145 rpm 175 rpm 145 rpm 180 / 320 rpm
Pad/Brush Size 20” (51 cm)
Power 1 hp 1.5 hp 0.9 / 1.5 hp
Gearbox 2 Planet 3 Planet
Cord Length 50’ (15 m)
Handle Tube Tubular Steel
Main Frame Die Cast Aluminum
Height w/handle 46” (117 cm)
Weight w/cord 87 lbs. (39.5 kg) 95 lbs. (43.1 kg) 81 lbs. (37 kg)
