30
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
ACCESSORIES AVAILABLE
A range of accessories is available from your Clarke dealer which extends the
versatility of your machine. These are as follows:
EXTERNAL JAWS - 3-JAW CHUCK
To change the jaws, insert the chuck key and open the jaws to their fullest
extent. It will then be possible to remove each jaw in turn.
1 Independent 4-Jaw Chuck 80mm dia 7610721
2 Face Plate - 160mm dia 7610723
3 Moving Steady 7610724
4 Fixed Steady 7610722
5 Tailstock Drilling Chuck with a 30mm capacity 7610725
6 Headstock Centre (MT3) 7610726
7 Revolving Centre (Tailstock - MT2) 7610727
8 6 Piece Cutting Tool Set
Comprising tools for 60
o
thread cutting, parting/grooving,
facing and general turning work. Hex. wrench not shown)
7610728
9 Metric Thread Cutting Kit (not shown)
Comprising Leadscrew, Half Nuts and Dial Indicator
7610720
