7
GENERATOR OVERVIEW
NO DESCRIPTION NO DESCRIPTION
1 Fuel level gauge 10 AC plug sockets (2 x 230V)
2 Fuel tank cap 11 Dipstick
3 Engine switch 12 Drain plug
4 Power Indicator 13 Starting handle
5 Voltmeter 14 Air filter
6 AC breaker 15 Fuel supply valve
7 DC reset Button 16 Muffler
8 DC 12V outlet 17 Spark plug
9 Earth Terminal
