21
3.0 Weights and tension values
Timing belts
Belt type Belt type Belt Tension Mass
New belt Run in belt
N N kg/m
HiTD 5M 9 99 71 0,0369
5M 15 174 124 0,0614
5M 25 311 222 0,1024
8M 20 372 266 0,1282
8M 30 593 424 0,1922
8M 50 1 037 741 0,3204
8M 85 2 044 1 460 0,5447
14M 40 1 297 926 0,4289
14M 55 1 912 1 366 0,5897
14M 85 3 142 2 244 0,9114
14M 115 4 480 3 200 1,2331
14M 170 7 139 5 099 1,8228
STPD S8M20 390 279 0,1109
S8M30 620 443 0,1673
S8M50 1 110 793 0,2782
S8M85 2 030 1 450 0,4732
S14M40 1 340 957 0,4620
S14M55 1 925 1 375 0,6343
S14M85 3 165 2 261 0,9811
S14M115 4 465 3 189 1,3268
S14M170 6 975 4 982 1,9621
Timing belts XL 025 13 11 0,0136
XL 037 24 20 0,0203
LO50 51 41 0,0433
LO75 87 70 0,0650
L 100 122 98 0,0867
H075 220 176 0,0838
H100 311 249 0,1117
H150 485 388 0,1675
H200 667 534 0,2233
H300 1 045 836 0,3350
XH 200 907 726 0,5718
XH 300 1 428 1 142 0,8577
XH 400 2 019 1 615 1,1436
XXH 200 1 130 904 0,8087
XXH 300 1 748 1 398 1,2130
XXH 400 2 478 1 982 1,6173
The following tables are suggested tension values for power transmission belts
manufactured by SKF
®
(SKF is a registered trademark of the SKF Group).
