Clavis Type 7 User Manual

22
Wrapped V, wedge and banded belts
Belt
type
Smallest pulley
diameter
Speed range Belt tension per
single belt*
Mass
New belt Run in Single belt Belt in a
band**over incl. over incl. belt
mm rpm N N kg/m
Z 40 60 1 000 2 500 104 69 0,0598 n/a
2 500 4 000 121 81
60 over 1 000 2 500 174 116
2 500 4 000 174 116
A 75 90 1 000 2 500 332 222 0,1083 0,1496
2 500 4 000 254 169
90 120 1 000 2 500 391 261
2 500 4 000 332 222
120 175 1 000 2 500 469 313
2 500 4 000 411 274
B 105 140 860 2 500 469 313 0,1867 0,2598
2 500 4 000 391 261
140 220 860 2 500 567 378
2 500 4 000 528 352
C 175 230 500 1 740 1 017 678 0,3099 0,4173
1 740 3 000 841 561
230 400 500 1 740 1 251 834
1 740 3 000 1 115 743
D 305 400 200 850 2 210 1 473 0,6347 0,8701
850 1 500 1 877 1 251
400 510 200 850 2 698 1 799
850 1 500 2 268 1 512
SPZ 56 79 1 000 2 500 338 226 0,0793 n/a
2 500 4 000 262 175
79 95 1 000 2 500 383 255
2 500 4 000 415 276
95 over 1 000 2 500 477 318
2 500 4 000 438 292
SPA 71 105 1 000 2 500 575 383 0,1341 0,1550
2 500 4 000 524 349
105 140 1 000 2 500 696 464
2 500 4 000 628 418
140 over 1 000 2 500 872 581
2 500 4 000 876 584
SPB 107 159 860 2 500 978 652 0,2083 0,2683
2 500 4 000 941 627
159 250 860 2 500 1 255 837
2 500 4 000 1 116 744
250 over 860 2 500 1 496 997
2 500 4 000 1 275 850
