23
* Multiply the belt tension required for a single belt by the number of the
belts in the banded belt unit to get total tension to apply.
** Multiply the mass of one belt in a band by the number of the belts in the
banded belt unit to get total mass to apply.
Wrapped V, wedge and banded belts
Belt
type
Smallest pulley
diameter
Speed range Belt tension per
single belt*
Mass
New belt Run in Single belt Belt in a
band**
over incl. over incl. belt
mm rpm N N kg/m
SPC 200 355 500 1 740 2 026 1 350 0,3804 0,4398
1 740 3 000 2 043 1 362
355 over 500 1 740 2 305 1 537
1 740 3 000 2 671 1 781
3V 61 90 1 000 2 500 313 209 0,0762 0,1024
2 500 4 000 274 182
90 175 1 000 2 500 430 287
2 500 4 000 391 261
5V 171 275 500 1 740 1 134 756 0,2228 0,2717
1 740 3 000 997 665
275 500 500 1 740 1 369 912
1 740 3 000 1 291 860
8V 315 430 200 850 2 933 1 955 0,5450 0,6158
850 1 500 2 386 1 590
430 570 200 850 3 520 2 346
850 1 500 3 129 2 086
Cogged raw edge V, wedge and banded belts
Belt
type
Smallest pulley
diameter
Speed range Belt tension per
single belt*
Mass
New belt Run in Single belt Belt in a
band**
over incl. over incl. belt
mm rpm N N kg/m
ZX 40 60 1 000 2 500 119 80 0,0576 n/a
2 500 4 000 139 93
60 over 1 000 2 500 199 133
2 500 4 000 199 133
AX 75 90 1 000 2 500 372 248 0,1100 0,1530
2 500 4 000 293 196
90 120 1 000 2 500 450 300
2 500 4 000 391 261
120 175 1 000 2 500 508 339
2 500 4 000 450 300
