6.2. Installation / Use of 230VAC Output
Fuses
Both 230VAC outputs on the LPS (Schuko on the front, Neutrik in the back) are protected with 8A relays
and a RCD, which allows you to make fixed 230VAC installations in the vehicle. If an installation is wired
around the LPS, separate relays must be used.
Connections
For fixed 230VAC installations from the LPS the Neutrik 230VAC Out on the backside must be used. This is
to ensure that vibrations will not loosen the connection.
General function
When 230VAC In is connected the 230VAC power will be looped directly through the unit.
If both 230VAC In and 230VAC Out are running and 230VAC In is subsequently disconnected, the LPS will
change from charge to discharge mode and continue to deliver 230VAC Out.
