Lithium Power Supply User Manual
!
Page 8
!
!
!
4. Lithium Power Supply - General parameters
Table 1
Battery type
100Ah-12V (LiFePO
4
)
Battery capacity
100Ah
(1320Whr)
Available capacity
80Ah
(1050Whr)
AC Input Voltage
207 VAC – 253 VAC
AC Input frequency
45 Hz – 65 Hz
AC Input power
(Charge power)
1000 W
(4,5A)
AC Output voltage
230 VAC pure sine
AC Output frequency
50 Hz
AC Output power – Continuously
1300 W
rms (6A)
AC Output power – 15 min
1500 W
rms (6,5A)
AC Output current Continuously
(with 230VAC input connected)
1800W (8A) / Socket
(Total max 2300W (10A))
AC Output power peak
(10sec)
2500 W
rms
DC Input voltage
12 - 15 VDC
DC Input continuous current
< 50 A
DC Output Voltage
13,2 VDC
(9,2 - 15 VDC)
DC Output continuous current
60 ADC
DC Output Max Impulse current
20 min
70 A
1 min
100 A
10 Sec
150 A
Operating temperature
(Output will be limited below 0°C)
-20°C~50°C
Cooling
Forced air (fan)
Self-discharge rate per month (Sleep mode)
< 3%
Operating mode self consumption
(Only DC Output active)
5 W
Operating mode self consumption
(Inverter and DC Output active
22 W
Sleep mode consumption
< 25 mW
Connection 230VAC
Neutrik and Schuko
Connection 12VDC
Anderson SB50
IP rating
IP21
Product Weight
28 kg
Product dimensions in mm (H x W x L)
250 x 244 x 390
Package weight
32 kg
Package dimensions in mm (H x W x L)
350 x 355 x 495
