Lithium Power Supply User Manual
!
Page 9
!
!
!
Table 2
Protection Class
Class I
(Do only connect to a Residual-current device (RCD) protected source)
Certifications
• 2014/35/EU (Low voltage directive)
EN 62368-1: 2014 (Safety, Information technology equipment)
• 2014/30/EU (EMC directive);
EN 61000-6-3: 2007 + A1:2011 Emission household
equipment
EN 61000-6-2: 2005 Immunity industrial
Safety protections
• 230vac Input protected by 10AT fuse
(Not replaceable)
• 230vac Output Protected by 2 x 8A fuse
(Resetable)
• DC Input Protected by 3 x 40A ATO fuses
(replaceable)
• DC Output Protected by 3 x 40A ATO fuses
(replaceable)
• Lithium battery protected by fuse
(Not replaceable)
• L/N relay hazard is hardware protected.
• PE/N relay hazard is hardware protected.
Additional
protections
230vac AC Output protections
• Overload
• Short circuit
230vac AC Input protections
• Over / Under voltage
• Frequency
• Controlled charge levels
DC Input
• Over / Under voltage
• Overload
• Controlled charge levels
DC Output
• Overload
• Controlled charge levels
(reverse on output)
Internal Lithium battery protections
• Over charge
• Deep discharge
• Temperature
• Overload
