Clayton LPS - Physical Dimensions and Mounting Overview

Lithium Power Supply User Manual
!
Page 10
!
!
!
5. Physical dimensions and mounting overview
ATTENTION: Mount the LPS topside up, never upside down or on the side.
ATTENTION: The LPS has forced air cooling. Make sure air can flow freely around the unit.
The LPS has four M5 mounting holes in the bottom as shown in figure 1.
Figure 1
244.00
3
8
6
.
0
0
2
5
.
0
0
25.00194.00
25.00
194.00
3
0
3
.
0
0
4 x M5
