R S - 6 0 1 B E L T P A C K
Figure 3: Pinouts of RS-601 Computer Connector
Figure 4: Back of RS-601Beltpack
PIN FUNCTION
Tip SDO to computer
Ring SDI from computer
Sleeve Common

4JEFUPOF
"EKVTUNFOU
